Pocket Cut-Up Tubular Key Machine
Pocket Cut-Up Tubular Key Machine
HPC

Pocket-Cut-Up - Tubular Key Cutter

In stock
SKU: HPC-TKM-90
$473.14



The Pocket Cut-Up™ (TKM-90) is a compact, portable tubular key machine. It is factory preset to cut standard size center sequence tubular keys by code.

Offset left and offset right sequence (including dead pin cuts) can be cut with one simple adjustment. It also cuts most Greenwald style tubular keys.

The tubular key blank is held firmly in place by the swing-away key holding fixture, that locks the depth adjustment knob at pre-selected depths. By turning the cutter knob, brass or steel key blanks are cut with ease. The Pocket Cut-Up™ is so incredibly lightweight and compact that it can be carried in your pocket.





TECHNICAL INFORMATION
Key Machine Model Number....................#TKM-90
Weight...............................13 oz/0.4kg
Machine Size (inches)...........2" dia x 4" long
Machine Size (metric)...................5 x 10cm
Cutter Supplied:
 1) HPC Pocket Cut-Up Cutter................#CW-TKM
Accessories Included:
 1) Key Decoder.............................#TKPD-1
 2) Allen Wrench 3) Instructions
The TKM-90 will cut:
 Standard Size................0.375" (9.53 mm) O.D. 0.312" (7.92 mm) I.D.
 Greenwald....................0.375" (9.53 mm) O.D. 0.312" (7.92 mm) I.D.
