Xhorse Dolphin II XP-005L XP005L Key Cutting Machine For All Key Lost
What is new compared with Dolphin XP-005?
>>Newly add Angle-adjustable LCD touch screen and Protective Shield
>>M5 Clamp (No need to frequently replace M1 and M2 clamps_
>>Update online directly: Machine firmware and database upgrade via WiFl, no need use xhorse update kit software
>>The indicator light changes colors with the change of real-time working status.
Featuring HD touchscreen with self-developed system, a protection shield providing a cleaner and safer working environment and 3 intelligent indicator light, DOLPHIN XP-005L comes with the best virtues you could ever want.
The workbench is upgraded and lengthened, the working space is expanded and optimized, the stability is enhanced, and the multi-directional safety protection brings you more security.
Xhorse XP-005L Features & Functions:
1. All Key Lost
2. Key Duplication
3. Built-in Lithium Battery, More Portable, Only 13KG, Easy to carry.
4. Customize Key Data
5. Optical Key Bitting (work with Xhorse key reader)
6. Multi-purpose M5 Clamp (No need to frequently replace M1 and M2 clamps)
7. Cut by Bitting
8. Find Bitting
9. Take Photos to Recognize Bitting
10. Recognition (Work with KEY READER)
11. Massive Vehicle Key Database Built- in powerful database covers over 100 car brands, 2,000 car models and 20,000 key data.
12. New Angle Adjustable 5-lnch HD Touch Screen, Transparent Protective Shield
13. Smart APP Control (Wi-Fi and Bluetooth)
14. Free Online Update
14. Free Online Update
15. The indicator light changes colors with the change of real-time working status.
16. Dolphin XP-005L Device Language: English Only
Xhorse APP Language: English, German, Spanish, French, Thai, Polish, Italian, Portuguese, Hindi, Hebrew, Korean, Indonesian, Chinese
Xhorse XP005L Structure:
Xhorse Dolphin II Software overview
Supporting self-calibration
Supporting key duplication and cutting for vehicle keys
Supporting universal key decode for multiple key types
Operation on APP through Bluetooth
Xhorse Dolphin XP-005L Clamp:
1. M5 Clamp (No need to frequently replace M1 and M2 clamps_
M5 clamp with two sides of A and B. Users can turn the clamp surface to cut according to cutting needs, it's no need to repeated install and uninstall to replace clamps. Here are the method of using the M5 clamp.
1) Loosen the "key lock knob" counter clockwise to make the right slider of the clamp the right limit
2) Turn the movable module clockwise, and turn the clamp from side a to side B. Tighten the key lock knob" clockwise to lock the clamp.
2. Optional M3, M4 Clamp (You need buy separately)
Xhorse Dolphin XP-005L Highlights:
HD Touch Screen
Users can directly control the device on its screen. High definition screen minimizes eye fatigue.
The machine adopts an angle-adjustable 5-inch capacitive touch screen. You can set the angle of the screen by actual needs.
Innovative Colorful Indicator Lights
The indicator light changes color with the change of real-time working status.
Red indicator – false alarm/error warning
Blue indicator – normal operation
Yellow indicator – information notification
Massive Vehicle Database
Built-in powerful database covers over 100 car brands, 2,000 car models and 20,000 key data. Accurate key data, detailed parameters, and clear key graphics. We provide a lifelong database upgrade service for free!
Portable Solution
Thanks to its compact design, lightweight, much easier to take it outside and provide users outdoor and roadside services.
Built-in well-known lithium battery, stable and reliable, support cutting works without power supply access.
Transparent Protective Shield
The transparent shield enables users to check the real-time working status while preventing metal debris from spattering.
Manufacture Craftsmanship
All-aluminum body structure; Manufactured by German-made DMG CNC machine to guarantee high precision cutting results. The finished keys passed the rigorous testing of the Optical Instrument.
A wider workbench, strong and steady, make your works more productive.
Maintain excellent performance even under extreme weather.
Multi-purpose Clamps
A wide duplication availability guaranteed by a variety of functional clamps, support multiple key types, standard single sided, standard double sided, 2 track external, 4 track external, dimple, channel track, 4 track internal, F021 & Citroen SX9 keys, residential keys, etc.
Support Bluetooth and WiFi
Support directly upgrade online via WiFi connection.
Control the machine by the Xhorse APP on your smartphone or other intelligent terminals via Bluetooth.
Dolphin XP-005L Specification:
Xhorse Dolphin XP-005L Vs Dolphin XP-005
16. Dolphin XP-005L Device Language: English Only
Xhorse APP Language: English, German, Spanish, French, Thai, Polish, Italian, Portuguese, Hindi, Hebrew, Korean, Indonesian, Chinese
17. Bind with VVDI MB Tool or VVDI Key Tool Plus, you will get 1 Free MB Token Everyday
Xhorse XP005L Structure:
Xhorse Dolphin II Software overview
Supporting self-calibration
Supporting key duplication and cutting for vehicle keys
Supporting universal key decode for multiple key types
Operation on APP through Bluetooth
Xhorse Dolphin XP-005L Clamp:
1. M5 Clamp (No need to frequently replace M1 and M2 clamps_
M5 clamp with two sides of A and B. Users can turn the clamp surface to cut according to cutting needs, it's no need to repeated install and uninstall to replace clamps. Here are the method of using the M5 clamp.
1) Loosen the "key lock knob" counter clockwise to make the right slider of the clamp the right limit
2) Turn the movable module clockwise, and turn the clamp from side a to side B. Tighten the key lock knob" clockwise to lock the clamp.
2. Optional M3, M4 Clamp (You need buy separately)
Xhorse Dolphin XP-005L Highlights:
HD Touch Screen
Users can directly control the device on its screen. High definition screen minimizes eye fatigue.
The machine adopts an angle-adjustable 5-inch capacitive touch screen. You can set the angle of the screen by actual needs.
Innovative Colorful Indicator Lights
The indicator light changes color with the change of real-time working status.
Red indicator – false alarm/error warning
Blue indicator – normal operation
Yellow indicator – information notification
Massive Vehicle Database
Built-in powerful database covers over 100 car brands, 2,000 car models and 20,000 key data. Accurate key data, detailed parameters, and clear key graphics. We provide a lifelong database upgrade service for free!
Portable Solution
Thanks to its compact design, lightweight, much easier to take it outside and provide users outdoor and roadside services.
Built-in well-known lithium battery, stable and reliable, support cutting works without power supply access.
Transparent Protective Shield
The transparent shield enables users to check the real-time working status while preventing metal debris from spattering.
Manufacture Craftsmanship
All-aluminum body structure; Manufactured by German-made DMG CNC machine to guarantee high precision cutting results. The finished keys passed the rigorous testing of the Optical Instrument.
A wider workbench, strong and steady, make your works more productive.
Maintain excellent performance even under extreme weather.
Multi-purpose Clamps
A wide duplication availability guaranteed by a variety of functional clamps, support multiple key types, standard single sided, standard double sided, 2 track external, 4 track external, dimple, channel track, 4 track internal, F021 & Citroen SX9 keys, residential keys, etc.
Support Bluetooth and WiFi
Support directly upgrade online via WiFi connection.
Control the machine by the Xhorse APP on your smartphone or other intelligent terminals via Bluetooth.
Dolphin XP-005L Specification:
|
Input voltage
|
24V DC
|
|
Power
|
160W
|
|
Principal axis rotation speed
|
12500rpm
|
|
Motor Torque
|
0.15N.m
|
|
LCD resolution
|
1280*720
|
|
Working temperature
|
-10-50_
|
|
Humidity
|
10-90%
|
|
Machine size
|
390mm*220mm*270mm
|
|
Package size
|
495mm*400mm*360mm
|
|
Net weight
|
13kg
|
|
Gross weight
|
18.5kg
|
Xhorse Dolphin XP-005L Vs Dolphin XP-005
|
Item
|
Xhorse Dolphin XP005L
|
Xhorse Dolphin XP-005
|
|
|
 |
 |
|
Screen
|
An angle-adjustable 5-inch capacitive touch screen, and users can directly complete operation on the screen.LCD resolution 1280*720.
|
Null
|
|
Bluetooth
|
Yes. Control the machine by the Xhorse app on your smart phone or other intelligent terminals via bluetooth
|
Yes,use smart cellphone or tablett to download APP via Bluetooth.
|
|
Wifi
|
Yes, directly upgrade online via wifi connection
|
Null
|
|
Protecting mask
|
Yes, prevent metal debris from spattering.
|
Null
|
|
Smart status indicator
|
Yes (in blue, yellow, red color)
|
Null
|
|
Multiple Clamps
|
Standard equipped M5 clamp (M1 and M2 2 in 1), optional M1/M2 Clamp, M3 Clamp, M4 Clamp.
|
Support clamps M1, M2, M3(optional) and M4 (optional)
|
|
Hexagon bar wrench
|
2mm+4mm 3mm hexagon bar wrench, 3mm hexagon bar wrench,6mm hexagon bar wrench
|
2mm hexagon bar wrench, 4mm hexagon bar wrench
|
|
Weight
|
Net weight 13KG, Gross weight 18.5KG
|
Net weight 15KG, Gross weight 18KG
|
|
Language
|
English, Spanish, French, Polish, Italian, Portuguese, etc
|
English, Spanish, French, Polish, Italian, Portuguese, etc
|
|
Update online
|
Machine firmware and database upgrade via Wifi directly
|
Online software update on APP, update through Xhorse"Upgrade Kit".
|
|
Key database
|
Yes, same as XP005
|
Yes
|
|
Function
|
Self-calibration, key duplication and cutting for vehicle keys, universal key decode for multiple key types.
|
Self-calibration, key duplication and cutting for vehicle keys, universal key decode for multiple key types.
|
- Xhorse Dolphin II has all the capabilities of the Xhorse Dolphin XP-005 but with improved safety and smart capabilities.
Xhorse Dolphin XP005L Package List:
1pc x Machine
1pc x Clamp M5 and link stopper
1pc x 1.5mm cutter
1pc x 2.5mm cutter
1pc x Probe
1pc x 2mm+4mm 3mm hexagon bar wrench
1pc x 3mm hexagon bar wrench
1pc x 6mm hexagon bar wrench
1pc x Power adapter
1pc x 1.5m Power cord
1pc x Brush
1pc x Product quality certificate
1pc x User manual
1pc x Machine
1pc x Clamp M5 and link stopper
1pc x 1.5mm cutter
1pc x 2.5mm cutter
1pc x Probe
1pc x 2mm+4mm 3mm hexagon bar wrench
1pc x 3mm hexagon bar wrench
1pc x 6mm hexagon bar wrench
1pc x Power adapter
1pc x 1.5m Power cord
1pc x Brush
1pc x Product quality certificate
1pc x User manual
