 Diameter |
 Thickness |
 Hole Diameter |
 Profile / Angle |
|||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Item No. | Type | Material | Inch | mm | Inch | mm | Inch | mm | A° | B° | F In. | mm |
| SACW-1012 | Milling | H.S.S. | 2.375 | 60.32 | .375 | 9.52 | .375 | 9.52 | 43 | 43 | .015F | .381 |
RAISE® High Quality Cutters
This cutter can be used on the following machines:
- Ilco Universal II
- HPC 1200CM
- Lagard LG1011
